#1, 3/4" x 1/2" Main Vent Valve
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
 --%3E %3Csvg version='1.1' id='Half' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cg%3E %3Cpath fill='%23F15C02' d='M30.05,70.23l3.79-12.01L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1h1.58 L93.71,7.18c-3.58-3.82-8.66-6.23-14.28-6.23H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,5.41,2.22,10.32,5.79,13.88 L30.05,70.23z'/%3E %3C/g%3E %3Cpath fill='%23FBC8B4' d='M93.71,7.18L60.98,39.6H91.2L65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82l5.55-17.59L6.75,93.32 c3.55,3.54,8.44,5.73,13.82,5.73h58.87c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,15.4,97.01,10.69,93.71,7.18z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$25.13 each
In Stock
Order by today, receive Tuesday
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
3/4" x 1/2"
Steam
240°F Max Temp
140°F Min Temp
140°F - 240°F
Straight
Description
–
Jacobus (Maid O' Mist) J1 Model #1 3/4" x 1/2" Main Vent Valve (3563000)
A straight, non-adjustable steam main vent used to release air from steam main lines so steam can fill the piping more quickly and evenly.
Key Features:
Compatibility & Applications:
Installation & Operation Notes:
Maintenance & Troubleshooting:
A straight, non-adjustable steam main vent used to release air from steam main lines so steam can fill the piping more quickly and evenly.
Key Features:
- Steam main vent (Application: Main Vent; System Type: Steam)
- Straight body pattern / mount
- Non-adjustable vent
- Connection size listed as 3/4" x 1/2", with male and female threads
- Vent size: 0.1850"
- Steel construction
- Temperature range listed as 140°F to 240°F
- Description: designed to vent air from main lines and longer runs depending on building size; suggested placement includes using one or more at the end of a short/warm-side main, and two or three at the end of a long/cold-side main
Compatibility & Applications:
- Intended for steam heating main venting applications (as listed/stated)
- Use on steam main lines and longer runs, with quantity guidance based on main length and building "warm side" vs. "cold side"
- Must only be used where the manufacturer specifies this exact part number/model: J1 (Model #1 / 3563000)
Installation & Operation Notes:
- Installation should be performed by a qualified steam/heating technician.
Maintenance & Troubleshooting:
- Main vents are commonly serviced or replaced when a steam system vents air poorly (slow heat), heats unevenly, or when an existing vent leaks or does not seal properly.
Specs
–
| Application: | Main Vent |
|---|---|
| Model: | #1 |
| System Type: | Steam |
| Size: | 3/4" x 1/2" |
| Adjustability: | Non-Adjustable |
| Max Temp (F): | 240°F |
| Min Temp (F): | 140°F |
| Temperature Range (F): | 140°F - 240°F |
| Vent Size: | .1850" |
| Mount: | Straight |
| Material: | Steel |
| Body Pattern: | Straight |
| Thread Type: | Female Male |
| Thread Size: | 1/2" 3/4" |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
Product Reviews
4.67 out of 18 reviews
94% would recommend this product
5 star
78%
4 star
17%
3 star
0%
2 star
6%
1 star
0%
Most Liked Positive Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Good main steam vent
Good quality main vent with decent venting capacity. Versatile threading (male 3/4" or female 1/2"), and removable orifice for cleaning. Got two of these to augment smaller steam vents on my residential mains that needed more venting. Roughly equivalent to a Gorton #1. Fairly compact vent so good if you don't have a lot of clearance.
VS
Most Liked Negative Review
Not what I ordered previously
I ordered six of these in 2012, and those are rock solid. However, the three I just received are now different than those previous six, and after installing them, two are not sealing well.
I wish I could find a main vent that doesn't leak as Gorton also changed and these are replacing several of those which have leaked since day one, even replacements of those Gorton leakers.
Showing 1-10 of 18 reviews
All good
Came quickly! Installed easily and is venting as expected.
Jeff
PA
9 months ago
Verified Buyer
Was this review helpful to you?
Prompt Service!
I was looking for an original Maid-o-Mist air valve for my steam boiler. Supplyhouse.com had just the part I needed. I would recommend their products.
Adrian
New York
2 years ago
Verified Buyer
Was this review helpful to you?
Main vent valve
Part arrived in a very good timely manner. Was identical to existing part. Took about 10 minutes to install....supply House rocks....
Joe
Ohio
3 years ago
Verified Buyer
Was this review helpful to you?
Plumbing needs
This is my go to place for my plumbing needs. Great service and quick delivery.
Buddy
New York
3 years ago
Verified Buyer
Was this review helpful to you?
Work great
Not only did I get the one above , I replaced some leakers with #4,5,and 6, will see how it goes this winter
Butch
Mi
3 years ago
Verified Buyer
Was this review helpful to you?
I would buy this product again.
This vent works very well.
Tom
Mohawk, NY
4 years ago
Verified Buyer
Was this review helpful to you?
Works fine- Quick Delivery
Replaced an almost new Gorton air valve that leaked steam with this one. It's woking fine. The delivery was ver fast.
Jack
Bronx, NY
5 years ago
Verified Buyer
Was this review helpful to you?
You get what you pay for!
I purchased main vent valves on 2 occasions from 2 places. Both were the same type : China made in a plastic bag. They leaked steam every time turning my basement into a sauna. I saw this advertised (American made but more expensive) and figured, "why not try'? Well they worked. My boiler has not needed water in 2 months. (Used to top off every other day) I am so pleased I purchased these brand for every vent in the house. The heating system has never worked better! Life lesson learned.
Mike
NYC
5 years ago
Verified Buyer
Was this review helpful to you?
yes
Good service - good price !! Whats not to like !
Alfie !
Blue Island IL>
5 years ago
Verified Buyer
Was this review helpful to you?
I would buy from Supply House again.
Products arrived on time and performed as intended
Mcgyver
Queens NY
