VA9203 24V On/Off Electric Spring Return Valve Actuator (27 lb-in)

Note: Valve is not included with actuator.

The VA9203-xxx-xx Series Electric Spring Return Ball Valve Actuators are direct-mount valve actuators that operate on AC/DC 24 V power. These bidirectional actuators are used to provide accurate positioning on Johnson Controls® VG1000 Series 1/2, 3/4, and 1 in. (DN15, DN20, and DN25) ball valves in Heating, Ventilating, and Air Conditioning (HVAC) applications. A mechanical spring return system provides rated torque with or without power applied to the actuator.
