$30.46 each
In Stock
Get 17 Tue, Jul 7
Order by today, receive Tuesday
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
120v, 240v, 480V
Description
–
Features:
- Timings: 2
- Switches: 4
- Resistive (Non-Inductive) at 480 VAC Watts: 6000
- Timings - Off M3-M4: 1-110
- Motor Ratings (Inductive) at 120 VAC Full Load: 10.0A
- Timings - Off M7-M8: 1-110
- Pilot Duty at 120 VAC: 125VA
- Timings - Off M1-M2: 1-110
- Resistive (Non-Inductive) at 480 VAC Amps: 12.5
- Timings - Off M5-M6: 1-110
- Motor Ratings (Inductive) at 480 VAC Locked Rotor: 18.0A
- Timings - On M1-M2: 1-110
- Timings - On M3-M4: 1-110
- Timings - On M5-M6: 1-110
- Timings - On M7-M8: 1-110
- Motor Ratings (Inductive) at 240 VAC Full Load: 5.0A
- Motor Ratings (Inductive) at 240 VAC Locked Rotor: 30.0A
- Resistive (Non-Inductive) at 120 VAC Amps: 25
- Resistive (Non-Inductive) at 240 VAC Watts: 6000
- Motor Ratings (Inductive) at 480 VAC Full Load: 3.0A
- Motor Ratings (Inductive) at 120 VAC Locked Rotor: 60.0A
- Resistive (Non-Inductive) at 240 VAC Amps: 25
- Resistive (Non-Inductive) at 120 VAC Watts: 3000
- Pilot Duty at 240 VAC: 125VA
- Pilot Duty at 480 VAC: 480VA
- Type: 2-DPDT
Specs
–
| Application: | Electric Heating |
|---|---|
| Type: | DPDT 2-DPDT |
| Voltage: | 120v 240v 480V |
| Switches: | 4 |
| Timings: | 2 |
| Timings On: | 1-110 |
| Timings Off: | 1-110 |
| A.C. Resistive: | 3000W 6000W 12.5A 25A |
| Pilot Duty Rating: | 125 VA @ 240 Vac 480 VA @ 480 Vac |
