Description
Direct Replacement for Most Fan/Heat Sequencing Functions. Terminal Markings are Equivalent to Competitive Types.

Features
  • Replaces Honeywell, MARS, TOD,GEMLINE, Klixon (Texas Instruments).
  • 24V input control
  • Multi-poise mounting
  • Any contacts (except M1 & M2) can be used as auxiliary contacts
  • Double quick-connect terminals for combination loads
  • Ambient Temperature Rating: -50 to 165 Degrees F
Hide Description
Manuals (2)
Specs
Application:

Electric Heating

Voltage:

120v

240v

480v

Switches:

2

Timings:

1

Timings On:

1-20

Timings Off:

40-110

Ambient Conditions:

-50 to 165ºF

A.C. Resistive:

3000W

6000W

12.5A

25A

Electrical Ratings (AFL):

7 A @ 240 VAC

14.0 A @ 120 Vac

Electrical Ratings (ALR):

72 A @ 120 VAC

42 A @ 240 VAC

Pilot Duty Rating:

480 VA @ 480 Vac

125 VA @ 120 Vac

125 VA @ 240 Vac

×
