$29.45 each
In Stock
Order by today, receive Monday
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
480V, 240v, 120v
Description
–
Features:
- Timings: 2
- Switches: 3
- Resistive (Non-Inductive) at 480 VAC Watts: 6000
- Timings - Off M3-M4: 1-110
- Motor Ratings (Inductive) at 120 VAC Full Load: 10.0A
- Pilot Duty at 120 VAC: 125VA
- Timings - Off M1-M2: 1-110
- Resistive (Non-Inductive) at 480 VAC Amps: 12.5
- Timings - Off M5-M6: 1-110
- Motor Ratings (Inductive) at 480 VAC Locked Rotor: 18.0A
- Timings - On M1-M2: 1-110
- Timings - On M3-M4: 1-110
- Timings - On M5-M6: 1-110
- Motor Ratings (Inductive) at 240 VAC Full Load: 5.0A
- Motor Ratings (Inductive) at 240 VAC Locked Rotor: 30.0A
- Resistive (Non-Inductive) at 120 VAC Amps: 25
- Resistive (Non-Inductive) at 240 VAC Watts: 6000
- Motor Ratings (Inductive) at 480 VAC Full Load: 3.0A
- Motor Ratings (Inductive) at 120 VAC Locked Rotor: 60.0A
- Resistive (Non-Inductive) at 240 VAC Amps: 25
- Resistive (Non-Inductive) at 120 VAC Watts: 3000
- Pilot Duty at 240 VAC: 125VA
- Pilot Duty at 480 VAC: 480VA
- Type: DPDT-SPST
Specs
–
| Application: | Electric Heating |
|---|---|
| Type: | SPST DPDT |
| Voltage: | 480V 240v 120v |
| Switches: | 3 |
| Timings: | 2 |
| Timings On: | 1-110 |
| Timings Off: | 1-110 |
| A.C. Resistive: | 12.5A 3000W 6000W 25A |
| Pilot Duty Rating: | 125 VA @ 240 Vac 480 VA @ 480 Vac |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
Compare Similar Products
Brand
Voltage
You May Also Need
Product Reviews
4.33 out of 3 reviews
67% would recommend this product
5 star
67%
4 star
0%
3 star
33%
2 star
0%
1 star
0%
Showing 1-3 of 3 reviews
I would buy this again and again!
This sequencer (stacked relay) is a common component used in electric heat banks within heat pumps and electric furnaces that are installed in many mobile home HVAC systems. That said, this model is one of several models used as such, and this one worked to get my customer's furnace working again. I keep at least 1 is stock on my service van just for cases like this.
WIZARD
Carlisle, Pa.
18 days ago
Verified Buyer
Was this review helpful to you?
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
i will not buy again
home electric heat worked for three month stuck closed had to replace
ken
greeenfield in
6 years ago
Verified Buyer
Was this review helpful to you?
I would buy it again
Works great no complaints
Markde6
Lyles ,Tennessee
8 years ago
Verified Buyer
Was this review helpful to you?
