006-IFC Stainless Steel Circulator Pump w/ Integral Flow Check, 1/40 HP
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$467.63 each
In Stock
Get 8 Wed, Jul 8
MANUALS (2)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
115V
1/40 HP
3 Year Warranty
Union, Flanged x Flanged Connection
9 MAX GPM
125 MAX PSI
Description
–
The 006-IFC with an Integral Flow Check (IFC) is designed for the circulation of hot or chilled fresh water in open or closed loop applications. The IFC feature simplifies piping, eliminates separate in-line flow check, reduces installation costs and improves system performance. With its patented location at the impeller inlet, the IFC is easy to service without removing the entire unit from system piping. The unique, replaceable cartridge contains all of the moving parts and allows for easy service instead of replacing the entire circulator.
Features:
- Integral Flow Check (IFC) Patent# 5,664,939
- Prevents gravity flow / reverse flow
- Eliminates separate in-line flow check
- Reduces installed cost
- Improves system performance
- Easy to service
- Unique replaceable cartridge - field serviceable
- Unmatched reliability-Maintenance free
- Quiet, efficient operation
- Self lubricating, No mechanical seal
- Wide Range of applications
- Bronze Construction with 1/2" & 3/4" Sweat Connections or Stainless Steel Union Connections
Specs
–
| Application: | Zoning |
|---|---|
| Material: | Stainless Steel |
| Amperage: | 0.52 |
| Horse Power: | 1/40 |
| Max Flow (GPM): | 9 |
| Flow Range (GPM): | 0-9 |
| Connection Type: | Union Flanged x Flanged |
| Temperature Range (F): | 40°F to 220°F |
| Voltage: | 115V |
| Max Pressure (PSI): | 125 |
| Type: | Pump |
| Max Head (Ft): | 8.5 |
| Head Range (ft.): | 0-8.5 |
| Hertz: | 60 |
| Phase: | 1 |
| RPM: | 3250 |
| Warranty: | 3 Year |
Contact
+
Happy Independence Day!
Our Customer Support will be closed today in honor of Independence Day. We will be back tomorrow to answer your questions.
Call or text 888-757-4774
Special Hours
Closed Now
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
Product Reviews
Showing 1-1 of 1 reviews
No mounting flanges available.
This calculator uses a 1 1/2 inch half flange but they are on back order until end of January or February 2023, be sure the flanges are available before ordering. Had to order flanges from another company that had them in stock.
FrankieG
Mooers NY
4 years ago
