This item replaces: 0389306
Lift Gate
–
This product weighs 207 lbs. and may require the use of a lift gate. If you do require a lift gate at your delivery, you'll have the option to add this FREE of charge when you checkout.
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
2-1/2"
Yes
Cast Iron
175 MAX PSI
Flanged x Flanged Connection
140°F, 110°F Max Temp
Description
–
Watts LF007 Double Check Valve Assemblies prevent the backflow of contaminated water into the potable water supply. It consists of a bronze (1/2 to 2 in) or fused epoxy coated cast iron (2 1/2 to 3 in) body construction that is easy to maintain and service. Watts Series LF007 is ideal at referenced cross-connections identified as non-health hazard applications. Check with local inspection authorities for installation requirements. Maximum Working Pressure: 175psi (12.06 bar).
Specs
–
| Product Type: | Backflow Preventer |
|---|---|
| Application: | Plumbing |
| Size: | 2-1/2" |
| Material: | Cast Iron |
| Max Pressure (PSI): | 175 |
| Max Temp (F): | 140°F 110°F |
| Temperature Range (F): | 33°F to 110°F |
| Min Temp (F): | 33°F |
| Lead Free: | Yes |
| Height: | 25-7/16" |
| Features: | UL/FM outside stem and yoke resilient seated gate valves |
| Connection Type: | Flanged x Flanged |
