Product Highlights
Description
Specs
| Application: | Accessory |
|---|---|
| Size: | 1/2" |
| Insertion Length: | 3" |
| Shell ID: | 3/8" |
| Bulb Size: | 3/8" x 3" |
| Insulation: | 1-1/2" |
| Capillary Diameter: | 5/64" |
| Material: | Copper |
Questions?
Compare Similar Products
You May Also Need
Product Reviews
I would buy this product again
yes
Great experience
The part I needed at a great price!
What can I say? It was the correct part and it works!
Boiler well 3/4 "
A Capillary thermostat well.
Worked as expected
Aquastat
SupplyHouse.com has everything to meet your plumbing needs
Product Q&A
5 QuestionsQ: Will this well work with aquastat L8148J1009?
Asked by Jaindesi 9 years ago
Add your answer
Verified Reply- SupplyHouse StaffYes, this well will work with L8148J1009 aquastat.
Q: Does this well work with Aquastat L6006A 1145?
Asked by Susan 12 years ago
Add your answer
Yep, that's what it's made for.
Susan, Yes, that WELL will work just fine with the L6006-1145 aquastat. I do not have the part numbers handy but there are at least four Honeywell WELLS that will work with the various immersion well type aquastats. There is a long and a short version (from threads to mounting groove) and ¾” and ½” pipe threads. Other variations also exist but they are more specialized. Hope that helps. Mike
yes it does the well is made to have the aquastat connect to it even mount to it. these to parts are made for each other. thad Sent from my iPad
Q: What aquastat well fits L4007B
Asked by Big R 13 years ago
Add your answer
1/2" Aquastat Well SKU:121371A Brand: Honeywell
Q: Can I use this well to make L6006C1018 a well aquastat versus only a strap on?
Asked by Mark 13 years ago
Add your answer
Yes and no. The aquastat will work as designed, but you would need to acquire/manufacture the clamp plate to attach it to the well.
I am thinking you have a strap on type of temp probe you want to put into a well. Not sure, but the gains and cost to do as you are wanting to would not necessaraly be worth the cost/time. A well installed strap on probe is a hard to beat method with me! Hope I was of help.
Q: Does this fit the Honeywell L4008A1015 SPST and does it come with the clamp to fasten the bulb in the well?
Asked by 15 years ago
Add your answer
Verified Reply- PexSupply StaffYes it does, as that aquastat has a 3/8" bulb.
