MANUALS (4)
Product Highlights
Description
Features and benefits
- Convenient single lever control:
Makes them easy to use and encourages shut-off of water supply. - Full Port Ball Valve:
Allows water to flow freely through valve. - Instant push-fit connections for increased ease of use:
No soldering, clamps, unions, or glue required. - Valve assembled to strict quality standards:
Measured thread engagement, measured torque.
Specs
| Size: | 1/2" |
|---|---|
| Max Pressure (PSI): | 200 |
| Material: | Brass |
| Application: | Heating Plumbing |
| Warranty: | 25 Year |
| Fitting System Compatibility: | Push Fit |
| Tubing Compatibility: | OD Controlled Copper PEX CPVC |
| Standards Met: | ASTM F1960 NSF ASTM F877 |
| Max Temp (F): | 200°F |
| Insertion Depth: | 15/16" |
Questions?
Compare Similar Products
Plumbing
You May Also Need
Product Reviews
Most Liked Positive Review
Believe the hype
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
No. Hire a plumber
Shark bite
No. Hire a plumber
these company gets it done
Great
I would buy this product again.
Quick Delivery, Accurate order
Great Product and a outstanding company to buy from
Quick Ship= Very happy
good
Will buy again
Product Q&A
10 QuestionsQ: 1) what's the difference between this product and the other 1/2" shutoff, SKU:24735LF ? I only need a couple, so the extra cost would be worth it if there is some benefit. 2) when inserting into a pipe, what is the gap - i.e. how much pipe needs to be removed so that this valve will fit correctly ?
Asked by idler 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffThis product (22222-0000LF) is a standard SharkBite Ball Valve while the 24735LF is a Slip ball valve. The slip feature makes it easier to install in some copper applications. The 22222-0000LF measures about 3.06" long, while the slip valve 24735LF requires 2" of piping to be removed for installation. Please see the following installation guides for more info on removing pipe for installation: http://s3.supplyhouse.com/product_files/Cash-Acme%20-%2022222-0000LF%20-%20Install%20Instructions.pdf http://s3.supplyhouse.com/product_files/24735LF-product.pdf
Q: I have heard that the sharkbite conections can only be used with Pex-b and not Pex-a (i.e. AquaPex or the Propex system). In researching I find that both types of Pex have the same manufacturing specs regarding diameter so am curious why they would not work with Pex-a.
Asked by JK 12 years ago
Add your answer
Verified Reply- SupplyHouse StaffSharkBite fittings may be used with either PEX-A or PEX-B tubing. However, only PEX-A tubing may be used when connecting with ProPex expander fittings.
Q: can these ball valves be used to replace gate valves?
Asked by 14 years ago
Add your answer
Verified Reply- PexSupply StaffYou can use this to replace a gate valve, however, it is a ball valve not a gate valve. It will work like a ball valve.
Yes, these can be used to effectively replace gate valves.
I know of no reason why a ball valve would not operate where a gate valve does. Having said this, I suggest reading wikipedia on gate valves (http://en.wikipedia.org/wiki/Gate_valve), then consider if there is any unique property of your gate valve which would make a ball valve less desirable. I can think of none, but I have been caught before!! Good luck.
Q: Are the sharkbite 1/2" ball valves releasable??
Asked by 15 years ago
Add your answer
Verified Reply- PexSupply StaffSharkBite fittings can be removed with the proper removal clip/tool.
All SB connections are releasable. You can purchase the release tool for the size you are up against or you can size a adjustable wrench around the pipe and it works the same. The secret is push against SB fitting pull out pipe. I believe the SB website has a video if you need further detail.
Q: HELLO,I WOULD LIKE TO KNOW THE TOTAL LENGTH FROM END TO END.THANK YOU SUPERCHIEF
Asked by SUPERCHIEF 15 years ago
Add your answer
Verified Reply- PexSupply StaffFrom end to end, this valve measures approximately 4 1/2".
Q: are these shark bite fittings for pex piping?
Asked by 16 years ago
Add your answer
Verified Reply- PexSupply StaffYes, these fittings are for PEX piping.
Yes, these fittings work with 1/2" Pex, or copper, or PVC. These are very versatile and provide instant connection.
Q: Is theis a full bore or full port ball valve
Asked by Kmann 16 years ago
Add your answer
Verified Reply- PexSupply StaffThis is a full bore ball valve.
I believe this valve to be a full port ball valve
Full bore
Q: Product in picture looks like it is a regular ball valve with sharkbite fittings added to it. The others I see are more compact & look like one piece. What is the difference?
Asked by Bob 16 years ago
Add your answer
Verified Reply- PexSupply StaffThe item you would receive would be one piece with SharkBite fittings on both ends.
Q: how long do they last
Asked by 16 years ago
Add your answer
Verified Reply- PexSupply StaffThese SharkBite fittings have a 25 year warranty. If the fitting is installed properly there should be no reason that they would not last indefinitely in a system. If you were turning the valve on and off to an excess then you might wear the packing out but that would not effect the connection itself.
Q: Is this product lead free?
Asked by 16 years ago
Add your answer
Verified Reply- PexSupply StaffThis specific SharkBite item has small traces of lead, but is approved in all states except California and Vermont.
There is a lead free version of this valve available, as with most Cash-Acme Sharkbite fittings. Just look for "LF" at the end of the product SKU.
