Product Highlights
Description
The LFMMV series can be set to any temperature between 80°F and 120°F with flow rates as low as 0.5 gpm and as high as 12 gpm. This mixing valve series is listed under ASSE Standard 1016 for single fixture applications, ASSE 1017 for hot water source applications and ASSE 1070 for single or multiple fixture applications.
The LFMMV series uses a double throttling design to control both the hot and cold water supply to the mixed outlet. The superior flow characteristics of this valve provide accurate temperature control (3¬F) with low pressure drop across the rated flow range.
As an added feature the LFMMV series incorporates integral inlet filter washers and check valves in both the hot and cold water inlets to protect against cross flow.
The LFMMV is available with either union thread (-UT), union solder (-US) connections. Adapters can be used to connect to CPVC or PEX end connections.
Specs
| Size: | 1/2" |
|---|---|
| Lead Free: | Yes |
| Standards Met: | ASSE 1069 ASSE 1017 ASSE 1070 |
| Application: | Point of Use Point of Source Heating |
| Max Temp (F): | 120°F |
| Material: | Bronze |
| Connection Method: | Sweat |
| Connection Type: | C x C |
| Max Pressure (PSI): | 150 |
| Temperature Range (F): | 80°F - 120°F |
| Min Temp (F): | 80°F |
| Body Pattern: | 3-Way |
Questions?
Compare Similar Products
ASSE 1017
ASSE 1070
Point of Source
Heating
You May Also Need
Product Reviews
Most Liked Positive Review
Watts 3/4
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Not quite up to specs
Great Service and Supplies
TRASH CAN
WORKS GREAT UNTIL IT DOESNT
Thought it would last longer
Watts 1/2" Mixing Valve, Sweat Ends
Works pretty well.
A good product at a great price
So far so good
EXCELLENT PRICE, GOOD SERVICE
Great product-easy to install, easy to adjust
Product Q&A
5 QuestionsQ: Does this valve offer internal replacement kit-if thermalstic portion fails, or does one need to replace the whole valve?
Asked by Curt 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffYes, Watts offers a repair kit for the 0559118 which is part number 0559123.
Q: What is the warranty on this valve?
Asked by Curt 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffWatts warrants this unit for one year.
Q: How. Do I adjust the water temperature of the water
Asked by Jim 14 years ago
Add your answer
loosen top of plastic cap and turn to desired temoerature than tighten cap back down
You have to loosten, the small screw on the handle and pull it out. Then turne it left or right depending on the temperature u want. Tge know has a lock to it and the only way it will turne is if the screw is loose and pulled out. After that just follow the instructions on the tag. Hope this helps. Robert Orban
Loosen screw on top of knob, then lift up on knob and turn; right to decrease temp and left to increase temp.
Hi To adjust the temp of the water: Take the hex wrench that is supplied (or one from your toolbox) and loosen the screw on the top of the plastic knob. Once loosened, lift the plastic knob about 1/8 inch and it will unlock from the valve body. The direction of turning is indicated on the valve (or instructions) - one way will add more from the hot side, and the opposite turn will add more from the cold side. The valve will operate with the screw loose, so you may want to test the output temp before retightening the screw. Once the temp is OK, reset the knob down on the valve and lightly retighten the screw so it will not move. Hope that helps.
You have to loosen the screw on top of the knob a bit in order to pull the knob out to unlock it and allow it to turn to adjust the temperature Sent from my U.S. Cellular® Android-powered phone
You put a thermometer or a temperature sensing strip on the outlet pipe, and turn the plastic knob ( the one with the paper tag on it) right or left to let in more or less hot water. When the output temp matches what temp you need, you are set.
Simply loosen the screw in the center of the cap far enough to let the cap rotate(about 1/4-3/8 inch), then adjust the temperature by pulling the cap out(away from the body) and rotating the plastic cap(counter-clockwise for hotter and vice-versa).
Q: What is the maximum hot water inlet temp.?
Asked by 14 years ago
Add your answer
Verified Reply- PexSupply StaffThe manufacturer recommends hot water inlet temperatures between 120°F and 180°F.
Q: I'm have one of these in my home. The BRASS union style nut has cracked on me. Am i able to order just the nut or do i have to get the WHOLE thing?
Asked by skidkid 16 years ago
Add your answer
Verified Reply- PexSupply StaffThe union style nut is not offered seperately so the whole unit would have to be replaced.
