76,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (LP)
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
' fill='%23F15C02' d='M49 0C21.938 0 0 21.938 0 49s21.938 49 49 49 49-21.938 49-49S76.062 0 49 0m0 82.709a7.54 7.54 0 1 1 0-15.08 7.54 7.54 0 0 1 0 15.08m7.54-28.412a7.541 7.541 0 0 1-15.08 0V22.831a7.54 7.54 0 0 1 15.08 0v31.466z'/%3E%3C/svg%3E)
MANUALS (4)
Replacement Parts
Product Highlights
Description
The Triangle Tube brand has been discontinued by the manufacturer as of 11/3/2025. Suggested replacement units will be available on our website and replacement parts will continue to be available as supplies last. If you'd like any further assistance, please contact our customer service team.
Note: Product Title reflects this boiler's IBR Net Output Rating
Overview:
The Prestige condensing wall mounted boiler features a uniquely designed stainless steel heat exchanger and offers 96% efficiency. The Prestige is capable of a firing rate of 25% of its rated input, meaning fewer cycles, resulting in lower operating costs. The unique TriMax Control makes installation fast and easy with a 60 second easy set-up. The TriMax allows for multiple circulators and temperature zones and has an integrated cascade feature to join mutiple boilers.
Boiler Features:
- Stainless Steel Fire Tube Heat Exchanger
- EZ Access Terminal Strips w/ Individually Fused High Voltage Terminals
- Outdoor Reset Sensor
- Negative Pressure Regulated Gas Valve
- LP Conversion Kit (except for Solo 110)
- Low Pressure Drop
- Category IV Venting
- NPT Piping Connections
- 30 psi Pressure Relief Valve
- Integrated Pressure Gauge
- Automatic Air Vent
- Fold-Down Control Panel
- Condensate Trap
- Multiple Termination Options
- Low NOx 2012 SCAQMD Certified
- 10-Year Non-Prorated Heat Exchanger Warranty
- 60 Second Set Up
- Large Graphic Interface
- 6 Preset & Customizable Reset Curves
- Standard ModBus Interface
- 2 Space Heating Call Inputs
- Controls up to 4 Circulators
- 0-10 VDC Modulation Input
- Outdoor Reset
- DHW Priority
- Warm Weather Shutdown
- Low Water Cutoff
- Intelligent Troubleshooting - describes lockouts, stores solutions, stores last 8 errors and records sensor readings for 24 hours
Triangle Tube Boiler Installation & Warranty Information:
We recommends that the installation of all Triangle Tube Boilers be done by a licensed, trained and qualified technician with the proper knowledge and background.
Should you experience an issue during the installation or the initial startup of the unit, please do not contact the manufacturer. You should have the technician that installed the unit contact either us or the manufacturer. Triangle Tube cannot accept any service or warranty calls from anybody but a licensed technician.
Neither we, or Triangle Tube can be held liable for improper installation and operation of any Triangle Tube boiler product purchased from our company. Should a warranty issue arise where parts will need to be replaced, an installation receipt will be required along with your sales receipt. Failure to provide a receipt or invoice may result in the warranty not being honored.
This boiler is compatible with the below manifold:
PTRKIT126: Timesaver Primary Secondary Piping Manifold (1.25" SWT)
Specs
| Product Type: | Boiler |
|---|---|
| Fuel Type: | Propane |
| Efficiency: | 96% |
| System Type: | Hydronic (Water) |
| Features: | Direct Vent EI/Spark Ignition Condensing Wall Mounted |
| Gas Connection: | 1/2" |
| Vent Diameter: | 2" 3" |
| Vent Type: | PVC Direct Vent CPVC Polypropylene AL29-4C |
| Supply Size: | 1" |
| Return Size: | 1" |
| BTU Input: | 87000 |
| IBR Rating: | 76000 |
| DOE Rating: | 87000 |
| Depth (Inches): | 16" |
| Width (Inches): | 20" |
| Height (Inches): | 35.5" |
| Weight (lbs): | 105 lbs |
| Application: | Heating |
Questions?
You May Also Need
PT110 (LP)
Replacement Parts
SKU: PT110LP
Brand: Triangle Tube
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Need help finding a replacement part?
Product Reviews
trapped at home by high tech boiler
Product Q&A
2 QuestionsQ: The manual is kinda confusing on venting material.Will PVC work for both intake and vent and can it go out the wall touching the wood or does it need a sleeve? Not sure how hot the pipes get.
Asked by shane 12 years ago
Add your answer
Verified Reply- SupplyHouseThe PVC concentric sidewall venting will require a field supplied metal thimble for mounting the concentric vent kit through the wall. For additional information on installation and required clearances,please see pg 8 here: https://d3501hjdis3g5w.cloudfront.net/manuals/1284996284320/39319_PROD_FILE.pdf
Q: what is needed to hook up the boiler?
Asked by fred 13 years ago
Add your answer
Verified Reply- SupplyHouseInstallation requirements and procedure can be found in the user guide located here on our site : https://d3501hjdis3g5w.cloudfront.net/product_files/Prestige%20110%20TriMax-User%60.pdf
