4-Wire Normally Closed Thermal Actuator for Bluefin Manifolds
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$80.84 each
In Stock
Get 53 Tue, Jul 7
Order by today, receive Tuesday
MANUALS (2)
This item replaces: MA-ACT-4-WIRE
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
Rifeng Manifolds
Normally Closed
Plastic
24V
200 MAX PSI
ASTM F1960, ASTM F877, NSF Standards Met
Description
–
4-Wire Normally Closed Thermal Actuator for Bluefin Manifolds
- Power (Brown & Blue wires): Connect 24 VAC from the thermostat or pump control module - Brown = 24 VAC Hot, Blue = 24 VAC Common.
- End Switch (Black & Grey wires): Dry-contact circuit that closes when the actuator reaches its end position, used to signal another device (e.g., boiler or pump).
Note: this product is compatible with Rifeng Manifolds.
Specs
–
| Application: | Zoning |
|---|---|
| Type: | Thermal |
| Wiring: | Four-Wire |
| Used With: | Rifeng Manifolds |
| Product Type: | Actuator |
| Position: | Normally Closed |
| Material: | Plastic |
| Switch: | End Switch |
| Voltage: | 24V |
| Max Pressure (PSI): | 200 |
| Standards Met: | ASTM F1960 ASTM F877 NSF |
| Max Temp (F): | 200°F |
| Manifold Compatibility: | Bluefin Manifold Rifeng Manifold |
Contact
+
Happy Independence Day!
Our Customer Support will be closed today in honor of Independence Day. We will be back on Sunday to answer your questions.
Call or text 888-757-4774
Special Hours
Closed Now
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
Product Reviews
5 out of 3 reviews
100% would recommend this product
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Showing 1-3 of 3 reviews
Perfect fit
I was able to create separate zone for my master bathroom. Now my master bedroom and bathroom have different temperature controls
Jacob
Staten Island NY
3 months ago
Verified Buyer
Was this review helpful to you?
Work great, used with Caleffi manifolds
I bought these in 2022. They are easy to install and work great on my Caleffi manifolds. Caleffi actuators I also used on some of my manifolds, installed the same time, had caps fall off and one of them failed. I am replacing that one with Bluefin.
trekkie
Cliffside Park, NJ
6 months ago
Was this review helpful to you?
Better then cheap actuators builder installed
Would buy with confidence again.
Michael S.
Staten Island, NY
6 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
3 Questions3 Questions
Q: I'm replacing and older one but the wires are now a little different. Originals two green blue /black and now the new has black / brown/ blue/ gray what goes where. Help me please
Asked by Adsm 7 years ago
Add your answer
Verified Reply- Supplyhouse.com TeamSupply House has no installers or technicians on staff to advise on proper installation. Bluefin is one of our overseas manufacturers from China and they provide little information in regards to installation besides the Product Overview below. Please contact a local electrician if you have further questions. https://s3.amazonaws.com/s3.supplyhouse.com/product_files/Bluefin-HMACT4-Product-Overview.pdf
Was this review helpful to you?
Q: Are these actuators normally closed or normally open?
Asked by SCOTT 9 years ago
Add your answer
Verified Reply- SupplyHouse StaffNormally closed
Was this review helpful to you?
Q: Is it possible to wire in two of these actuators together for a single zone? I will have two runs of 1/2 inch pex in each zone.
Asked by Adam 9 years ago
Add your answer
Verified Reply- SupplyHouse StaffYes, it is.
