Description
Features:
  • Reversing plug
  • 50C Ambient
  • 115 Volt
  • Auto Protector
  • Open Construction
  • 1/2" Dia.- Flatted Shaft
  • Continuous Air Over
  • Permanent Split Capacitor
  • 60C Ambients
  • 23" Leads (Minimum)
  • High Efficient $
  • 48 Frame (5-5/8" Dia.)
  • 60 HZ
  • Multiple Mount
  • Reversible
  • Resilient Mounting Ring Included
Read more
Manuals (1)
Specs
Type:
Permanent Split Capacitor
Horse Power:
1/4
Bearings:
Sleeve
Voltage:
115v
Duty:
Air Over
Mount:
Resilient Rings
Poles:
6
RPM:
1075
Rotation:
Reversible
Phase:
1
Enclosure Type:
Open Air Over
Speeds:
3
Frame:
48Y
Insulation Class:
A
Amperage:
4.3
Features:
High Efficiency
Overload Protection:
Automatic
Max Ambient Temp (°F):
122°F
Motor Orientation:
Any
×
