| Application: | Electric Heat (Line Voltage) |
|---|---|
| Stages: | 1 Heat |
| Programmability: | Programmable 7 Day |
| User Interface: | Push Button |
| Mount: | Vertical |
| Power Method: | Hardwired |
| Operating Temp Range: | 32°-120°F |
| Temperature Range (F): | 40°F - 80°F |
| Voltage: | 240v 208V |
| Amperage: | 16.7 |
| Switch Action: | SPST |
| Hertz: | 60 |
| Electric Connection: | 6" Tinned Copper Lead Wires |
| Color: | White |
| Height: | 4.9" |
| Width: | 2.8" |
| Depth (Inches): | 9/10" |
| Humidity Control: | No |
| Wireless: | No |
It does not, but Honeywell-Aube part TH115-AF-GA is a similar thermostat that does have ground-fault protection.
I don't think this will work for a 2 wire installation, which was also my problem and I couldn't figure out. I went with the Aube TH106, which works great, but is also nearly twice as big with no backlight. No complaints on operation though.
All line-voltage digital thermostats (programmable or otherwise) require four wires (two from the main, two going to the heater(s)). This is because these type of thermostats, unlike mechanical thermostats, require a constant power supply (the pair from the mains). You cannot install such a thermostat into a junction box with only two wires available because such a circuit only has power when the heater is running. The TH115-A-240S-B is rated for up to 4000 W (16.7 V), which seems to be the highest rating of any comparable device.
