| Shutoff Head (ft.): | 18' |
|---|---|
| Type: | Automatic |
| Cord Length: | 8' |
| Volume: | 3.5 Gallons |
| Horse Power: | 1/3 |
| Voltage: | 115V |
| Amperage: | 9 |
| Wattage: | 720 |
| Flow at 5 FT Head: | 45 GPM |
| Flow at 10 FT Head: | 29 GPM |
| Flow at 15 FT Head: | 12 GPM |
| Approvals: | UL/CSA |
| Dimensions: | 14.5"W x 10.5"H |
| Discharge: | 1-1/2" FNPT |
| Max Pressure (PSI): | 7.8 |
| Weight (lbs): | 24 lbs |
According to the manual, "Do not use a mechanical vent with this product. A mechanical vent will cause improper operation of the automatic switch."
its doesn't, it will overflow. no lint trap
Hello, Yes, this pump must be vented to properly function. There is a vent connection on the top of the pump to which a plastic pipe assembly (not supplied with pump) is attached. I hope this helps.
