$153.42 each
In Stock
Get 5 Tomorrow, Jul 3
Order by 6PM, receive Tomorrow
Size:
1"
Connection Type:
C x C
Features:
Standard
MANUALS (5)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
C x C Connection
1"
2.3 Cv
180°F Max Temp
3-Way
20 MAX GPM
Description
–
Taco's 5000 Series Heating Only version of mixing valves provides the high
performance temperature stability required for today's radiant heating systems.
It makes this mixing valve is an ideal choice for a radiant heating system
whether in slab, over pours or in joist bay heating installations. Add to that
multiple connection types such as straight NPT, union (sweat, threaded,
CPVC or Pex) and you have a series of mixing valve that will fit most of
your installation needs.
Features
Applications:
Features
- Delivers Stable Mixed Water Temperature
- Extended Mix Temperature Range of 85-176°F (29-80°C)
- Tamper-Resistance Cap
- Low Headloss
- Outlet Temperature Strip
Applications:
- Low Temperature and Radiant Systems
- In Slab
- Over Pours
- Joist Bay Heating Installations
Specs
–
| Features: | Standard |
|---|---|
| Connection Method: | Sweat |
| Connection Type: | C x C |
| Body Pattern: | 3-Way |
| Size: | 1" |
| Max Flow (GPM): | 20 |
| Max Pressure (PSI): | 230 |
| Flow Capacity (Cv): | 2.3 |
| Max Temp (F): | 180°F |
| Material: | Forged Brass |
| Application: | Point of Source Heating Only |
| Accuracy: | ±3°F |
Contact
+
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Special Hours
8am–6:45pm
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
Compare Similar Products
Brand
Connection Method
Connection Type
Size
Flow Capacity (Cv)
Max Temp (F)
You May Also Need
Product Reviews
3.67 out of 3 reviews
67% would recommend this product
5 star
67%
4 star
0%
3 star
0%
2 star
0%
1 star
33%
Showing 1-3 of 3 reviews
This mixing valve is junk
I bough this one to replace the one that I got 2 weeks before it. I tried to use it in in floor heat. I have a high end boiler that reads outside temperature to find its set point. This mixing valve could not handle the changing temperature it was all over the place 106 to 160 it had no control at all. The first one did the same thing. So I replaced it whit a Watts LFMMV-UT-M1 mixing valve now the in floor heat stays at 115 +/-1.
Chris
IL
6 years ago
Verified Buyer
Was this review helpful to you?
I would buy again
Mixes pretty well, i sould have bought the higher flow model for my application. Working for now
gary
Ohio
7 years ago
Verified Buyer
Was this review helpful to you?
Good product
I use it in a hot water floor heat system to reduce the temperature of the water going into the cement floor
Pat
Fergus Falls MN
9 years ago
Verified Buyer
Was this review helpful to you?
