SR504-4 has been discontinued
Discontinued February 10, 2026
This product was discontinued by the manufacturer.
MANUALS (3)
This item replaces: SR504, SR504-2
'/%3E%3C/svg%3E){kind=small}
Direct Replacement:
Product Highlights
–
120 VAC Input
4
10-1/4" Width
6.75" Height
2-3/4" Depth
20 Amps
Description
–
The Taco SR504-4 Switching Relay is the best choice for all your zoning needs, with advanced PowerPort Cards, external diagnostic lights, and contractor friendly PC board layouts. Combined with the time proven reliability of the 00 family of circulators and thermostats, total system integrating is achieved. External indicator lights provide instant diagnostic feedback, making a snap of service calls or new installation start-ups.
- 24-Volt power input or output terminal
- Fuse protected
- Simplified wiring
- Compact design
Specs
–
| Application: | Zoning |
|---|---|
| Number of Zones: | 4 |
| Width (Inches): | 10-1/4" |
| Height (Inches): | 6.75" |
| Depth (Inches): | 2-3/4" |
| Amperage: | 20 |
| Power Method: | 120 VAC Input |
| Voltage: | 120v |
