40 Gallon ENJ-40 ProLine Residential Electric Water Heater w/Side Connections - Lowboy (1PH, 4.5kW, 240V)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
MANUALS (3)
Lift Gate
Product Highlights
Description
The ProLine Lowboy Side Connect electric water heater is designed to take up as little room as possible and is the ideal choice for when installation space is limited to tight spaces such as under counters and in crawl spaces. With a 38-gallon (nominal) tank, the ENJ-40 delivers a first hour rating of 54 gallons at a Uniform Energy Factor of 0.93. The sacrificial anode helps protect the tank from the corrosive effects of water, and is accompanied by a 6-year limited tank warranty. A. O. Smith's ProLine water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.
- Delivers 54-gallon first hour rating
- Dual 4,500-watt commercial-grade heating elements deliver reliable and efficient hot water
- Lowboy water heater designed for installation under a counter, in a crawl space or in other tight spaces
- Side-mounted plumbing and electrical connections (optional top-mounted water connections for field conversion)
- Patented Blue Diamond glass tank lining protects against corrosion
- DynaClean automatic cleaning system protects against sediment build-up
- Stainless steel CoreGard anode rod protects against corrosion longer than ordinary anodes
- Commercial-grade brass drain valve for durable and easy operation
- CSA Certified and ASME Rated T&P Relief Valve, Factory-Installed
- 6-year limited tank and parts warranty
Specs
| Intended Household: | 2-3 Person |
|---|---|
| Application: | Plumbing |
| Kilowatts (KW): | 4.5 |
| Fuel Type: | Electric |
| Number of Elements: | 2 |
| Energy Star Rated: | No |
| Capacity (Gallons): | 38 |
| Voltage: | 240v |
| Phase: | 1 |
| Max Input (KW): | 6 |
| Max Pressure (PSI): | 150 |
| ASME: | Yes |
| 1st Hour Delivery (Gallons): | 46 |
| Energy Factor: | 0.95 |
| R-Value: | 12 |
| Recovery 90°F Rise: | 20.7 GPH |
| Depth (Inches): | 26" |
| Height (Inches): | 33.5" |
| Diameter (Inches): | 26" |
| Weight (lbs): | 115 lbs |
| Warranty: | 6 Year Tank/6 Year Parts Limited |
