4" x 6.5 Ft. SpeediChannel Line Set Cover (Natural)

4" x 6.5 Ft. SpeediChannel Line Set Cover (Natural)

The DiversiTech 230-D4A is a 4-inch wide, 6.5-foot long line set cover in natural color, designed to conceal refrigerant lines, drain lines, and control cables when in-wall installation is not possible. This cover is part of the SpeediChannel system, which features the unique SpeediClip for quick, single-person installation. The product ships ready to install and replaces the previous model 230-D4.

Key Features & Benefits

• Natural PVC Construction: Provides durable, weather-resistant protection for exposed line sets in a plain off-white finish.
• 4-Inch Width: Accommodates standard mini-split and HVAC line set bundles.
• 6.5-Foot Length: Covers significant distances with a single piece, reducing the number of required couplings.
• SpeediClip Installation System: Enables one-person installation without additional tools or complex procedures.
• Snap-Together Assembly: Halves join quickly and securely, streamlining the installation process.
• Compatible with Full SpeediChannel System: Works seamlessly with wall penetration covers, union couplings, elbows, bends, and other fittings in the DiversiTech 230 series.
• Paintable Surface: Accepts exterior paint for custom color matching to building exteriors.
• Internal Retainer Clips: Three sliding retainer points per 6.5-foot section allow zip-tie attachment to secure line sets inside the channel.

Compatibility & Requirements

This line set cover requires compatible SpeediChannel fittings such as the 230-WC4 wall penetration cover, 230-CP4 union coupling, 230-LFB4 90-degree long radius bend, and 230-TC46 reducer coupling for complete runs and transitions. Zip ties are not included and must be purchased separately to secure lines within the internal retainers. Installation should be performed by a qualified technician familiar with HVAC line set routing and local building codes. The cover is designed for exterior use and suits applications where line sets must remain visible but protected from damage and UV exposure.

Installation & Care

Plan the route and measure the total run length before ordering to ensure adequate coverage and appropriate fittings. Lay the bottom half of the channel along the intended path and place refrigerant lines, drain lines, and control cables inside. Use zip ties through the internal retainer clips to hold lines in position, spacing ties at regular intervals to prevent sagging. Snap the top half of the channel over the bottom half, starting at one end and pressing firmly along the length until both halves lock together. Install any required fittings such as elbows, bends, or couplings. Paint the installed cover with exterior-grade paint if color matching is desired, allowing adequate drying time before exposure to weather. Check all seams and connections periodically to confirm they remain secure and that no debris has entered the channel.

What's Included

• One 4-inch x 6.5-foot SpeediChannel line set cover section (two halves)
• Three internal sliding retainer clips pre-installed

Frequently Asked Questions

Q: What color is the SpeediChannel line set cover?
A: The cover is plain off-white PVC, referred to as natural color, and can be painted with exterior paint to match building exteriors.

Q: Does the cover come with zip ties for the retainer clips?
A: No, zip ties are not included and must be purchased separately to secure lines within the internal retainer clips.
