0011 Stainless Steel Circulator w/ Integral Flow Check, 1/8 HP

Brand:
Taco
SKU:
0011-SF4-IFC
Rating:
(1)
Q&A:
(0)
0011 Stainless Steel Circulator w/ Integral Flow Check, 1/8 HP
Magnifying glass
Hover image to zoom
$805.35 each
In Stock
In Stock
Get 4 Wed, Jun 25
Fast Track Logo
Order by today, receive Wednesday
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days

Product Highlights

Product Highlight: Voltage
115V
Product Highlight: Horse Power
1/8 HP
Product Highlight: Warranty
3 Year Warranty
Product Highlight: Connection Type
Flanged x Flanged Connection
Product Highlight: Max Flow (GPM)
30 MAX GPM
Product Highlight: Max Pressure (PSI)
125 MAX PSI

Description

Note: Full flange-to-flange three-year warranty on all 00 Series circulators.

The 0011-IFC with an Integral Flow Check is designed to reduce installation costs when zoning with 00® circulators on large residential / light commercial high head / medium flow applications such as hydronic or radiant heating, hydro-air fan coils, indirect water heaters or domestic water recirculation systems. By locating the removable, spring-loaded IFC inside the pump casing, a separate in-line flow check is eliminated, reducing installation costs. The reduced pressure drop of the IFC increases the 0011 flow performance over in-line check valves. Both the IFC and cartridge are easily accessed for service instead of replacing the entire unit. Taco's patented Priority Zoning circulator with built-in transformer, relay, priority switch and IFC in one complete, compact package to make it ideal for zoning.

Features:
  • Integral Flow Check: Prevents gravity flow, Eliminates separate in-line flow check, Reduces installed cost, Improves system performance, Easy to service
  • Unique replaceable cartridge-field serviceable
  • Unmatched reliability-maintenance free
  • Quiet, efficient operation
  • Direct drive - Low power consumption
  • Self lubricating, No mechanical seal
  • Standard high capacity output - Compact design
  • Wide range of applications
  • Flanged connections


Replacement Parts List:
Flange Gasket Set: 007-007RP
Capacitor or PC Board: 009-018RP
Cartridge Assembly Complete: 0011-010RP
Valve Assembly Trans/Relay: 0012-021RP

Specs

Application:

Heating

Material:

Stainless Steel

Horse Power:

1/8

Type:

Pump

Voltage:

115V

Hertz:

60

Phase:

1

Amperage:

1.76

RPM:

3250

Head Range (ft.):

0-31

Max Head (Ft):

31

Flow Range (GPM):

0-30

Max Flow (GPM):

30

Temperature Range (F):

40°F to 230°F

Max Pressure (PSI):

125

Connection Type:

Flanged x Flanged

Connection Size:

1-1/2"

1"

3/4"

1-1/4"

Warranty:

3 Year
