Universal Nitride Ignition Furnace Control
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$145.43 each
In Stock
Get 16 Tue, Jul 7
Order by today, receive Tuesday
MANUALS (4)
This item replaces: 50A65-288, 50A65-120, 50A65-143
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
Intermittent Hot Surface Pilot
Description
–
Control Gas Valve, Ignitor, Blower, Inducer, Humidifier and Air Cleaner
Features
Features
- Replaces OEM, Trane, York, ICP and Amana models
- Includes diagnostic indicator flash codes
- Replaces 50A65-120, -143, -288, -474, -475 controls (consult Integrated Nitride Module Reference Chart on spec sheet)
- Replaceable 3A fuse
- 60 minute auto reset
- Single channel flame sense
Specs
–
| Ignition Type: | Intermittent Hot Surface Pilot |
|---|
Contact
+
Happy Independence Day!
Our Customer Support will be closed today in honor of Independence Day. We will be back tomorrow to answer your questions.
Call or text 888-757-4774
Special Hours
Closed Now
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
Compare Similar Products
Brand
Ignition Type
CURRENT ITEM
Intermittent Hot Surface Pilot
You May Also Need
Product Reviews
4.88 out of 48 reviews
96% would recommend this product
5 star
96%
4 star
0%
3 star
2%
2 star
0%
1 star
2%
Customer Images
Most Liked Positive Review
Perfect!
The board in my Lennox G40 started to fail (cooling fan relay was dropping out intermittently) so I decided to replace it with this board which is indicated as one of the replacement options. It's the cheapest of all of the options and is the closest in size meaning all of the same holes line up. Also, the indicator LED is in the right place to see it from the original window of my furnace cover. I removed the unit from the plastic cover due to space reasons and figured it will probably get better cooling that way. It snapped into the same posts for the old board and all of the wires were simply plug and play into the same places. Made a couple of adjustments to the jumpers to match my old boards logic and test it out. Everything works perfectly! I would definitely purchase this again. A great and inexpensive solution and extremely easy to install. Took about 15 minutes. Supply House had the best price (of course) and shipped it super fast (as usual).
VS
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
It works, til it doesn't. This is how you can fix it
I've had two of these now. They each worked for about a year, then went into a fault that fried my blower motor. If you have one of these integrated furnace controls I would HIGHLY recommend only connecting one fan speed from your blower motor to this board.
The board has a heat blower setting and a cool blower setting. Normally people use high blower speed for AC/Cool and medium speed for heat/furnace.
The fault that happens with this board is that the relay that switches power onto the heat/cool settings will short out and provide power to BOTH heat and cool fan speeds at the same time! When your blower receives power on two different fan speeds at once it will blow it up and you'll be looking for a new motor.
My suggestion is, during the summer unplug the heat fan setting from the board and only connect your high speed fan leg to the cool blower setting. Put a cap on the open end of your other blower wires. During the winter unplug the cool blower setting from your motor and plug in your medium speed fan to the heat terminal. Keeping only one plugged in at a time will prevent this boards defect from destroying your blower motor and prevent you from having to replace the board as well.
This is an extremely common issue with this board and it always happens around 1 year after installation
Showing 1-10 of 48 reviews
Just what the furnace doctor ordered.
Solved a big problem with a very old furnace.
EEProf
Pittsburgh, PA
1 months ago
Verified Buyer
Was this review helpful to you?
Supply House has lowest price and fast shipping
The product is brand new and shipped in excellent protection. Plus Supply House has the lowest price per my google search on this item. I would buy again. HVAC control board has been installed and performs flawlessly!
kevatGeorgia
Norcross, Georgia
5 months ago
Verified Buyer
Was this review helpful to you?
Quality Part
I recieved this board in great packaging and in a timely manner. It has been working for a month now and it did not break the bank. Thank you SH
Leo
Colorado
6 months ago
Verified Buyer
Was this review helpful to you?
I would recommend
So far it's been working, and I'm happy with it. I have a Trane and it came with the jumper wire I needed for R1 to R3 which was easy to install in the 12 pin connector. It also came with other wires that I added to my extras. I have noticed that when it's quiet and the furnace and blower are running that I can hear in the vent what sounds like the blower slowed down just a little and maintained the same speed. Idk for sure what I'm hearing but sounds kind of like a quick pause in the supply vent when the blowers on. I read where someone else said that after around a year or so his sent current down the high speed and low speed at the same time causing blower motor problems and he recommended only hooking up the low speed wire during the winter and then only the high speed during the summer that way current can't be sent down both at the same time. I'm thinking about disconnecting the high speed connection since I'm only running my furnace and seeing if the slight pause I hear goes away.
Trane unit
Oklahoma
1 years ago
Verified Buyer
Was this review helpful to you?
very good company ,very good service！
good
tian
Georgia
1 years ago
Verified Buyer
Was this review helpful to you?
Yes
This control board is very easy to install and works great 👍🏻
Hsr
Woodbridge Va
2 years ago
Verified Buyer
Was this review helpful to you?
As listed.
Works fine!
Mika
Aspen, CO
2 years ago
Verified Buyer
Was this review helpful to you?
I have bought this product before! That's why I bought again
For me, it was easy to install. Just snap the board in and plug all the wires in. Simple. The people at Supply House are great! They got the parts to us the next day. Which was the best part. We are about to go through a severely cold snap. I was able to get our furnace up and running in time. The prices are really great too!
Moparman312
Spencer, IN
2 years ago
Was this review helpful to you?
It works, til it doesn't. This is how you can fix it
I've had two of these now. They each worked for about a year, then went into a fault that fried my blower motor. If you have one of these integrated furnace controls I would HIGHLY recommend only connecting one fan speed from your blower motor to this board.
The board has a heat blower setting and a cool blower setting. Normally people use high blower speed for AC/Cool and medium speed for heat/furnace.
The fault that happens with this board is that the relay that switches power onto the heat/cool settings will short out and provide power to BOTH heat and cool fan speeds at the same time! When your blower receives power on two different fan speeds at once it will blow it up and you'll be looking for a new motor.
My suggestion is, during the summer unplug the heat fan setting from the board and only connect your high speed fan leg to the cool blower setting. Put a cap on the open end of your other blower wires. During the winter unplug the cool blower setting from your motor and plug in your medium speed fan to the heat terminal. Keeping only one plugged in at a time will prevent this boards defect from destroying your blower motor and prevent you from having to replace the board as well.
This is an extremely common issue with this board and it always happens around 1 year after installation
Chase
Ohio
3 years ago
Was this review helpful to you?
Easy as can be
Old board had solder connections start to fail. Installed this in 10 minutes. Take a few pictures of the old board and even put labels on the wires if need be for easy installation when you swap them out.
Stef
Crystal Lake , Illinois
3 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
2 Questions2 Questions
Q: I have a lennox furnace model G23, with a white-rodgers board, do you have a replacement board for this unit. I belive the board is a 83M00.
Asked by Jack 15 years ago
Add your answer
Verified Reply- PexSupply StaffPart 83M00 is available on our site here: http://www.pexsupply.com/Lennox-83M00-Surelight-Circuit-Board-Kit
Was this review helpful to you?
Q: My 50A65-120 has an E33 spade terminal. The 50A65-843 which you sent to me does not. Do I have the wrong circuit board?
Asked by Joe 15 years ago
Add your answer
Verified Reply- PexSupply StaffThe 50A65-843 is listed by the manufacturer as the correct replacement for the 50A65-120. Please refer to the following Installation Instructions for details on wiring: http://s3.pexsupply.com/manuals/1303130499571/53732_PROD_FILE.pdf
