$56.25 each
In Stock
Get 48 Tomorrow, Jul 3
Order by 6PM, receive Tomorrow
MANUALS (2)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
10'
115V
13 Amps
Description
–
FOR USE WITH THE FOLLOWING ZOELLER PUMP MODELS:
"N" Models - 53, 55, 57, 59, 98, 137, 139, 140, 264, 266, 267, 268, and 282.
NOTE: Remove plug if present and use with "Junction Box" 10-0002 when field wiring is required.
Converts nonautomatic pump to automatic pump.
Features
"N" Models - 53, 55, 57, 59, 98, 137, 139, 140, 264, 266, 267, 268, and 282.
NOTE: Remove plug if present and use with "Junction Box" 10-0002 when field wiring is required.
Converts nonautomatic pump to automatic pump.
Features
- Simple installation
- Adjustable/variable level
- Standard 15' and 20' SJOW CPE cord with molded plug
- Float constructed of durable PVC/polypropylene encasing variable level switch
- Standard normally open (NO) 'pumps down'
- Optional normally closed available (NC) 'pumps up', consult factory
- Maximum operating temperature for 10-0748 is 120°F (49°C), all other switches 140°F (60°C)
- Float is omnidirectional (no 'up' side)
- Includes mounting clamp
- Designed for effluent, sewage and dewatering applications
- Variable level float switch, for use in 18" minimum diameter basins
- 10-0748, 25' cord standard, no molded plug, can be used as a control switch to operate an external magnetic or combination starter on three phase pumps
- Vertical piggyback float switch, ideal for narrow diameter basins - 6-1/2" maximum cycle range
- Use recommendation chart for switch selection
- Does not contain mercury
Specs
–
| Cord Length: | 10' |
|---|---|
| Product Type: | Switch |
| Application: | Accessory |
| Voltage: | 115V |
| Amperage: | 13 |
| Max Operating Temp: | 140°F |
Contact
+
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Special Hours
8am–6:45pm
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
Product Reviews
4.83 out of 6 reviews
100% would recommend this product
5 star
83%
4 star
17%
3 star
0%
2 star
0%
1 star
0%
Showing 1-6 of 6 reviews
Works as intended
Very happy, easy to install, works as intended. Received very quickly for fair price.
Very happy with supplyhouse.com will continue to use them.
Heli Rob
NE Pennsylvania
6 years ago
Verified Buyer
Was this review helpful to you?
I definitely will use this type of pump
Now if the switch on the pump fails I can easily by pass it
Poppy
Maryville Illinois
6 years ago
Verified Buyer
Was this review helpful to you?
Yes
Excellent product...installed and working well. Be sure the float clears the edge of the pit and observe operation, you do not want to interfere with the pump motor. I like making variable adjustments, depending on the depth and diameter of the sump pit. I had both of my sump pits dug out to a full 30 inches years ago. This is the best thing you can do, especially if you are in a water gathering area. Many sump pits are shallow.
Mark
Inverness, Illinois
6 years ago
Verified Buyer
Was this review helpful to you?
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
yes
Cheap and works assume
Walter ( Panda)
Denver CO
7 years ago
Verified Buyer
Was this review helpful to you?
Good Product
Easy to install and adjustable
Ali
IL
8 years ago
Verified Buyer
Was this review helpful to you?
Good Prodcut
Easy install works well
Ali
IL
8 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
1 Question1 Question
Q: CAN FLOAT BE USED IN DRINKING WATER?
Asked by Bill 14 years ago
Add your answer
Verified Reply- PexSupply StaffThis float switch is only recommended for use in sump/effluent/sewage applications.
