86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG) Zoom

86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG)

SKU:PT110

Brand: Triangle Tube

Triangle Tube
Qty Price
$3,198.95
/ each
In Stock! Ships in 24-48 Hours
(14 Available)
36

Resources

Specs

Product Type: Boiler
Fuel Type: Natural Gas
Efficiency:
?
96%
System Type: Hydronic (Water)
Features: Wall Mounted
Condensing
Direct Vent
EI/Spark Ignition
Gas Connection: 1/2"
Vent Diameter: 2"
3"
Vent Type: Direct Vent
PVC
CPVC
Polypropylene
AL29-4C
Supply Size: 1"
Return Size: 1"
BTU Input: 99000
DOE Rating:
?
99000
IBR Rating:
?
86000
Depth (Inches): 16"
Width (Inches): 20"
Height (Inches): 35.5
Weight (lbs): 105 lbs
Application: Heating

Description for Triangle Tube PT110

Note: Product Title reflects this boiler's IBR Net Output Rating

Overview: The Prestige condensing wall mounted boiler features a uniquely designed stainless steel heat exchanger and offers 96% efficiency. The Prestige is capable of a firing rate of 25% of its rated input, meaning fewer cycles, resulting in lower operating costs. The unique TriMax Control makes installation fast and easy with a 60 second easy set-up. The TriMax allows for multiple circulators and temperature zones and has an integrated cascade feature to join mutiple boilers.

Boiler Features:

  • Stainless Steel Fire Tube Heat Exchanger
  • EZ Access Terminal Strips w/ Individually Fused High Voltage Terminals
  • Outdoor Reset Sensor
  • Negative Pressure Regulated Gas Valve
  • LP Conversion Kit (except for Solo 110)
  • Low Pressure Drop
  • Category IV Venting
  • NPT Piping Connections
  • 30 psi Pressure Relief Valve
  • Integrated Pressure Gauge
  • Automatic Air Vent
  • Fold-Down Control Panel
  • Condensate Trap
  • Multiple Termination Options
  • Low NOx 2012 SCAQMD Certified
  • 10-Year Non-Prorated Heat Exchanger Warranty
TriMax Control Features:
  • 60 Second Set Up
  • Large Graphic Interface
  • 6 Preset & Customizable Reset Curves
  • Standard ModBus Interface
  • 2 Space Heating Call Inputs
  • Controls up to 4 Circulators
  • 0-10 VDC Modulation Input
  • Outdoor Reset
  • DHW Priority
  • Warm Weather Shutdown
  • Low Water Cutoff
  • Intelligent Troubleshooting - describes lockouts, stores solutions, stores last 8 errors and records sensor readings for 24 hours
This boiler is compatible with the below manifold:
PTRKIT126: Timesaver Primary Secondary Piping Manifold (1.25" SWT)

PLEASE NOTE: The product weighs 106 lbs. and may require the use of a
lift gate.
If you do require a lift gate at your delivery, you'll have the option to add this FREE of charge when you checkout.

86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG)

REVIEW SNAPSHOT®

by PowerReviews
Triangle Tube86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG)

5.0

(based on 2 reviews)

Ratings Distribution

  • 5 Stars



    (2)

  • 4 Stars



    (0)

  • 3 Stars



    (0)

  • 2 Stars



    (0)

  • 1 Stars



    (0)

Reviewed by 2 customers

Sort by

Displaying reviews 1-2

Back to top

(3 of 3 customers found this review helpful)


5.0

Easy Installation excellent boilers

By Carlo-lo-Jackle

from Atlantic Highlands, Jersey

Verified Buyer

Comments about 86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG):

I bought two of these boilers for post-storm heat restoration in a commercial building. Installation was straightforward and start-up was uneventful. The TriangleTube tech team sized the external circulation pumps for two loops of differing length efficiently and were in general totally helpful. I will mention two minor faults in hopes the manufacturer will take notice: 1. both left-hand latches for the tip-down control panel failed to engage, so any juggling during installation releases the right latch and the panel falls, quality control problem. 2, The electrical knock-outs in the bottom rail are PHENOMENALLY hard to knock out, meaning full force hammering with a 1/4 " tipped cold chisel. The bottom rail was distorted in both units before knock-outs were out, die punch for rail needs to penetrate further. Other than that: Fantastic, the units told me water pressure was low and when I had corrected it and when all the air in the system had been purged. Running extremely efficiently as we speak, totally pleased.

(8 of 8 customers found this review helpful)


5.0

Great boiler

By Bob S

from Portland, IN

Verified Reviewer

Comments about 86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG):

Just installed and started using Sept 1, 2012, is working great with the Smart 30 gal water heater. Have not run out of hot water yet. I installed the boiler myself with no problems. The manuals that came with the unit are well written and easy to understand. Very easy to program, no number codes like the old model, would work out of the box with no programing.

Displaying reviews 1-2

Back to top

Q&A: Ask the Questions, share answers

Do you have questions about this product?

get answers from real customers and in-house experts with AnswerBox.

2 Questions | 2 Answers
Displaying questions 1-2
  • 86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG)

    Q:

    With this boiler what temperature setting gets you to the maximum efficency? What about other temp vs. efficency?
    Asked on 8/2/2013 by Phoenix

    1 answer

    • CUSTOMER CARE

      A:

      This boiler operates most efficiently when return water temperatures are as low as possible. Flue gases can normally start to condense when return temperatures are below 150°F to 140°F.

      Answered on 8/2/2013 by PexSupply Staff from NY
  • 86,000 BTU Output Prestige Solo 110 Condensing Gas Boiler w/ TriMax Control (NG)

    Q:

    HI,
    I'M INSTALLING THIS TRIANGLE # PT-110
    BOILER WHICH CIRCULATES CENTRAL HEAT
    WATER AS WELL AS DOMESTIC WATER. NOW,
    IF I USE THE DHW FROM THE BOILER, DOES
    THIS WATER CONNECT DIRECTLY TO MY
    EXISTING WATER TANK? OR DOES IT REQUIRE
    AUXILIARY HEAT EXCHANGER?
    Asked on 7/27/2012 by Wealthy- new home owner from New York.n.y.

    1 answer

    • CUSTOMER CARE

      A:

      This boiler can be connected to an indirect water heater. Such tanks generally contain a coil through which boiler water can flow to heat domestic water sitting in the tank. The boiler would not work with a standard tank-style hot water heater.

      Answered on 8/3/2012 by PexSupply Staff from NY
