FS5-S-1, 1" Flow Switch w/ Stainless Steel body
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$1,478.68 each
Backorder
Get it Thu, Jul 30 - Thu, Aug 27
MANUALS (3)
This item replaces: FS5-S-1
'/%3E%3C/svg%3E){kind=small}
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
1"
7.4 Amps
120v, 240v
150 MAX PSI
32°F - 250°F
Description
–
For general purpose applications requiring low flow rate sensitivity
Features
Optional Features
Features
- In-line configuration eliminates need for a pipe tee
- Sizes available: 3/4" NPT, 1" NPT
- Materials of construction: Brass, carbon & EPDM elastomer (for water
- Models FS5 & FS5-D
- Stainless steel, carbon and Buna N (for water or water and petroleum base compounds)
- Models FS5-S & FS5-DS
- Single pole, double throw snap switch
- Sensitivity adjusting screw makes flow adjustment easy
Optional Features
- BSPT threads
- Minimum temperature (fluid or ambient) 32 Deg. F (0 Deg. C)
- Maximum temperature 225 Deg. F (107 Deg C) - Stainless Steel models 250 Deg. F (121 Deg C) - Brass
- Maximum operating pressure 150 psi (10.5 kg/cm2)
Specs
–
| Size: | 1" |
|---|---|
| Type: | General Purpose |
| Switch: | SPDT |
| Application: | Liquid Flow |
| Amperage: | 7.4 |
| Voltage: | 120v 240v |
| Max Pressure (PSI): | 150 |
| Hertz: | 60 50 |
| Temperature Range (F): | 32°F - 250°F |
