0014 Cast Iron Circulator, 1/8 HP
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
 --%3E %3Csvg version='1.1' id='Half' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cg%3E %3Cpath fill='%23F15C02' d='M30.05,70.23l3.79-12.01L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1h1.58 L93.71,7.18c-3.58-3.82-8.66-6.23-14.28-6.23H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,5.41,2.22,10.32,5.79,13.88 L30.05,70.23z'/%3E %3C/g%3E %3Cpath fill='%23FBC8B4' d='M93.71,7.18L60.98,39.6H91.2L65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82l5.55-17.59L6.75,93.32 c3.55,3.54,8.44,5.73,13.82,5.73h58.87c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,15.4,97.01,10.69,93.71,7.18z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$485.40 each
In Stock
Get 15 Wed, Mar 26
More Available
Order by 6PM, receive Wednesday
MANUALS (5)
This item replaces: 0014-ZF1-2
'/%3E%3C/svg%3E){kind=small}
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
115V
1/8 HP
3 Year Warranty
Flanged x Flanged Connection
32 MAX GPM
125 MAX PSI
Description
–
Note: Full flange-to-flange three-year warranty on all 00 Series circulators.
Taco 0014-F1 Circulator is designed for high head / medium flow applications in large residential and light commercial systems. Common uses include high mass boilers, commercial water heaters, and light commercial heating and cooling systems. Features the unique replaceable cartridge which contains all of the moving parts and allows for easy service instead of replacing the whole unit.
Features:
Applications:
Taco 0014-F1 Circulator is designed for high head / medium flow applications in large residential and light commercial systems. Common uses include high mass boilers, commercial water heaters, and light commercial heating and cooling systems. Features the unique replaceable cartridge which contains all of the moving parts and allows for easy service instead of replacing the whole unit.
Features:
- Unique replaceable cartridge-Field serviceable
- Unmatched Reliability --Maintenance Free
- Quiet, efficient operation
- Direct drive-Low power consumption
- Self-lubricating, No mechanical seal
- Standard high capacity output-Compact design
- Wide range of applications
Applications:
- Hydronic Heating/Cooling
- Radiant Heating
- Zoning with Pumps
- Hydro-Air Fan Coils
- And many others
Specs
–
| Material: | Cast Iron |
|---|---|
| Amperage: | 1.55 |
| Application: | Heating |
| Voltage: | 115V |
| Max Pressure (PSI): | 125 |
| Type: | Pump |
| Horse Power: | 1/8 |
| Connection Size: | 1" 1-1/4" 1-1/2" 3/4" |
| Flow Range (GPM): | 0-32 |
| Max Flow (GPM): | 32 |
| Max Head (Ft): | 22 |
| Head Range (ft.): | 0-22 |
| Hertz: | 60 |
| Phase: | 1 |
| RPM: | 3250 |
| Temperature Range (F): | 40°F to 230°F |
| Connection Type: | Flanged x Flanged |
| Warranty: | 3 Year |
