1 Zone 120V Switching Relay w/ Internal Transformer, 1 SPST Line Relay, RA89A1074
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$104.63 each
In Stock
Get 36 Mon, Jun 15
Order by today, receive Monday
MANUALS (2)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
120V
SPST
1
5-1/4"
10.2 Amps
120v
Description
–
Provide intermediate switching of a line voltage device from a low voltage controller
Features
Integral transformer provides low voltage power for control circuit.
Product Specifications
Features
Integral transformer provides low voltage power for control circuit.
Product Specifications
- Description: Switching Relay with internal transformer, for switching one line voltage load.
- Application Provide intermediate switching of a line voltage device form a low voltage controller
- Switching Action SPST
- Coil Ratings Current 0.4A
- Coil Ratings Voltage 24 Vac
- Temperature Range (F) 115 F maximum ambient for 60 Hz. 105 F Max. Ambient for 50 Hz.
- Temperature Range (C) 46 C maximim ambient for 60 Hz. 41 C maximum ambient for 50 Hz.
- Dimensions (in.) 5-1/4" high x 4-1/4" wide x 2-5/16" deep
- Dimensions (mm) 133 mm high x 108 mm wide x 59 mm deep
- Electrical Ratings - Primary Voltage 120V. 50/60 Hz
- Electrical Connections (Control Circuit) 2-Wire
- Approvals, Underwriters Laboratories Inc, Listed: File No. E4436, Guide No. XAPX
- Approvals, Canadian Standards Association, Certified: File No. LR1620
- Includes Integral transformer, enclosure
- Tradeline Value Tradeline
- Electrical Ratings (Maximum Input) 5.0 W Electrical Ratings (Primary Voltage) 120V, 50/60 Hz
- Contacts Electrical Rating Main Contacts 120 Vac 10.2A AFL. 61.2A ALR. 10A Resistive
- Contacts Electrical Rating Main Contacts 240 Vac 5.1AA ALF. 30.6A ALR. 6.0A Resistive
- Electrical Rating: Maximum Input 5.0W Contacts
- Electrical Ratings (120 Vac AFL) 10.2A AFL, 61.2A ALR, 10.0A resistive
Specs
–
| Ambient Conditions: | 105°-115°F Max 105 F Max for 50 Hz 115 F max for 60 Hz |
|---|---|
| Application: | Zoning |
| Number of Zones: | 1 |
| Width: | 4-1/4" |
| Height: | 5-1/4" |
| Amperage: | 10.2 |
| Power Method: | 120V |
| Voltage: | 120v |
| Depth (Inches): | 2-5/16" |
| Relays: | Spst Line Voltage |
| Switch Action: | SPST |
| Warranty: | 5 Year Limited |
