Description
Note: ProMax name is now ProLine.

Note: This model comes with side mounted recirculating taps.

The ProLine® XE Power Vent gas water heater is engineered to maximize efficiency while offering greater flexibility in installation options.

Featuring a 75-gallon tank and a 76,000 BTU gas burner, the GPVX-75L Power Vent delivers a recovery rate of 80.4 gallons per hour. It carries a 6-year limited warranty, and meets Low NOx emission requirements.

Features:
  • Note: This model is not ENERGY STAR Qualified
  • Dynaclean II dip tube optimizes inlet water pressure to minimize cold water regions within the tank. The self-cleaning action also reduces sediment accumulation on the bottom of the tank.
  • Hot-surface ignitor is more robust and reliable than standing pilot, and reduces energy consumption.
  • Built-in heat traps on the water inlet and outlet reduce the amount of heat lost through piping
  • 2-inch, thick, "Environmentally-Friendly" foam insulation reduces the amount of heat loss and contributes to overall energy efficiency
  • Versatile Power Vent Design
    • All models feature an exclusive 3-position rotatable blower outlet which adds flexibility
    • Combined horizontal and vertical vent runs up to 180 equivalent feet with 4" diameter venting (ABS, PVC, CPVC and polypropylene)
    • All models are equipped with a protected sensor that detects the presence of flammable vapors and automatically disables the burner to prevent ignition
    • Air intake snorkel elevates the inlet location of combustion air to prevent flammable vapors from entering the sealed combustion chamber
    • Reduced NOx emissions comply with air quality management district regulations
  • User-Friendly
    • State-of-the-art electronic gas control provides more precise temperature control
    • LED control light displays operation status and diagnostics information
    • Factory-installed T&P and a durable, tamper-resistant brass drain valve are positioned for service accessibility
  • Available in Natural Gas and Propane
  • 6 year limited tank and parts warranty
    The ProMax Power Vent water heaters have been engineered to maximize efficiency and deliver a greater energy factor (EF).
  • Read more
    Specs
    Application:
    Plumbing
    Intended Household:
    5+ Person
    Features:
    Side Connection
    Fuel Type:
    Natural Gas
    Capacity (Gallons):
    75
    BTU Input:
    76000
    Gas Connection:
    1/2"
    Water Connection:
    3/4"
    Vent Size:
    3"
    Venting:
    Power Vent
    Vent Size:
    4"
    Vent Type:
    Polypropylene
    CPVC
    ABS
    PVC
    Energy Star Rated:
    No
    Recovery 90°F Rise:
    80.4 GPH
    Height (Inches):
    70.625"
    Depth (Inches):
    33-1/8"
    Diameter (Inches):
    26"
    Weight (lbs):
    277
    Warranty:
    6 yr Tank/6 yr Parts Limited
    ×
