AO Smith XCG-50 50 Gallon 40,000 BTU ProLine Residential Natural Gas Water Heater, Tall Model, 10 Year Warranty
The AO Smith XCG-50 is a 50-gallon (48 gallons actual capacity) atmospheric vent residential natural gas water heater designed for standard homes with 3 to 4 people. Featuring a 40,000 BTU gas burner and 60.75-inch tall configuration, this ProLine model delivers an 81-gallon first hour rating (88 gallons per manufacturer specification) with a 10-year limited tank and parts warranty (6 year parts). The unit includes factory-installed heat trap nipples, an intelligent electronic gas control, and a patented eco-friendly Green Choice Gas Burner meeting Low-NOx emission requirements.
Key Features & Benefits
Compatibility & Requirements
Standard installation requires a 3-inch or 4-inch B-vent system for atmospheric venting. The unit connects to 3/4-inch water lines and a 1/2-inch natural gas supply line. Maximum operating pressure is 150 PSI. This water heater is designed for residential use and meets Low-NOx emission requirements for regulated areas. Installation by a qualified, licensed professional installer is required to maintain warranty coverage and ensure code compliance. Verify local building codes and gas line capacity before installation. The unit weighs 148 lbs and measures 60.75 inches tall by 21 inches in diameter (21 inches depth), requiring adequate clearance for service access and venting. Not ASME rated.
Replaces model XCV-50.
Installation & Care
Install on a level, non-combustible surface with required clearances per local codes. Connect 3/4-inch cold water inlet and hot water outlet using approved connectors. Attach 1/2-inch natural gas supply line with a manual shutoff valve. Install temperature and pressure relief valve in the designated opening and route discharge line to a proper drain. Connect atmospheric vent using 3-inch or 4-inch B-vent material sloped upward and terminating outdoors per code. Turn on water supply and purge air from lines. Open gas supply and light pilot using the push-button piezo ignitor. Set temperature using the electronic control dial. Monitor LED status indicator to confirm proper operation. Check all connections for leaks using soapy water. Avoid using the unit in areas subject to freezing or corrosive atmospheres. Inspect anode rod and drain tank periodically only if accessible without voiding warranty.
What's Included
Warranty & Support
The AO Smith XCG-50 carries a 10-year limited warranty on the tank and 6-year limited warranty on parts. Warranty coverage requires installation by a qualified, licensed professional installer and proper operation within specified parameters. Retain proof of purchase and installation records for warranty claims.
Frequently Asked Questions
Q: How tall is a 50-gallon water heater?
A: The AO Smith XCG-50 50-gallon tall water heater measures 60.75 inches in height with a 21-inch diameter.
Q: What is the first hour rating and recovery rate?
A: This unit delivers an 88-gallon first hour rating and recovers 41 gallons per hour with a 90-degree Fahrenheit temperature rise, suitable for households of 3 to 4 people.
| Energy Factor: | 0.62 |
|---|---|
| Intended Household: | 3-4 Person |
| Application: | Plumbing |
| Capacity (Gallons): | 48 |
| BTU Input: | 40000 |
| Fuel Type: | Natural Gas |
| Vent Type: | Atmospheric |
| Vent Size: | 3" 4" |
| Water Connection: | 3/4" |
| ASME: | No |
| Max Pressure (PSI): | 150 |
| Gas Connection: | 1/2" |
| 1st Hour Delivery (Gallons): | 88 |
| Recovery 90°F Rise: | 41 GPH |
| Energy Star Rated: | No |
| Diameter (Inches): | 21" |
| Depth (Inches): | 21" |
| Height (Inches): | 60.75" |
| Weight (lbs): | 148 lbs |
| Warranty: | 10 Year Tank/6 Year Parts Limited |
