WX-203 (146S30), 32 Gal WELL-X-TROL Well Tank (Steel Stand)
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$524.53 each
In Stock
Get 45 Fri, Jun 12
Order by today, receive Friday
MANUALS (6)
This item replaces: 146S30
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
32 Gallons
1" Connection
7 Year Limited Warranty
150 MAX PSI
45" Height
15-3/8" Diameter
Description
–
Amtrol WX-203 (146S30) 32 Gal WELL-X-TROL Well Tank (Stand) is a pre-pressurized steel well pressure tank for residential water systems, designed to deliver steady water pressure and reduce pump cycling.
Key Features:
Compatibility & Applications:
Installation & Operation Notes:
Maintenance & Troubleshooting:
Key Features:
- Tank volume 32 gallons
- 1" connection
- Factory precharged 38 psi
- Maximum pressure 150 psi
- Maximum temperature 200°F
- Height 47 inches
- Diameter 15 inches
- Shell high strength steel
- Diaphragm heavy duty butyl
- Liner antimicrobial
- System connection stainless steel
- Finish Tuf-Kote HG Blue
- Max acceptance factor 0.35
- Warranty 7-year limited
Compatibility & Applications:
- Controls pump cycling in residential well water systems.
- Can be used indoors or outdoors.
Installation & Operation Notes:
- Install upright on a stable, level surface.
- Connect to system piping using the 1" system connection.
- Verify and adjust air precharge to match pump cut-in setting per installation instructions.
Maintenance & Troubleshooting:
- Precharged diaphragm design with heavy duty butyl diaphragm and antimicrobial liner.
- Reference the Installation & Operation Instructions on the Amtrol site for setup, precharge adjustment, and service procedures.
Specs
–
| Tank Volume: | 32 Gallons |
|---|---|
| Max Accept. Factor: | 0.35 |
| Connection Size: | 1" |
| Precharged PSI: | 38 psi |
| Max Pressure (PSI): | 150 |
| Height (Inches): | 45" |
| Diameter (Inches): | 15-3/8" |
| Weight (lbs): | 43 lbs |
| Warranty: | 7 Year Limited |
| Max Temp (F): | 200°F |
| Coating: | Blue Enamel |
| Shell Material: | Steel |
| Diaphragm Material: | Heavy Duty Butyl |
| Liner Material: | Virgin Polypropylene |
| Application: | Plumbing |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
Compare Similar Products
Brand
Tank Volume
CURRENT ITEM
32 Gallons
You May Also Need
Product Reviews
4.79 out of 168 reviews
99% would recommend this product
5 star
86%
4 star
10%
3 star
4%
2 star
1%
1 star
1%
Customer Images
Most Liked Positive Review
Awesome service & Fast Shipping
I was impressed with all of the information online especially the measurements. My old Welltroll WX 202 20 gallon 32 years old and still going but I noticed it being weak and pressure dropped off quickly With a reduction in water flow. despite not being saturated. The New tank WX 203 32 gallon has the same diameter measurements just taller making the installation easier. I also bought the brass 10 inch T with Union so if need to change in future it will be a quick exchange. I also got the boiler valve and pressure relief valve and used my old adjustable pressure switch. I run my pressure 45/65 and adjusted the new tank to 43 pounds before installing.
My system now kicks in much less than before and pressure is holding at faucets without a reduced water flow like I had.
Shipping was fast and no damages on any of my parts. Much cheaper than local vendors.
Good Job guys
VS
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Well X Trol Quality Control Issues
This is a challenging review. SupplyHouse gets 5 stars, Amtrol the maker of Well-X-Trol pressure tanks, maybe 1 1/2 stars.
We are on our third tank and seem to have a good one finally. Ordered the first one in July and learned it was defective soon after. Started seeing the telltale rust in toilet bowls. SupplyHouse checked with Amtrol, they agreed to send another tank. I originally ordered a WX-203, what arrived was a WX-202. That is a 20 gallon tank instead of the 32 gallon I ordered. The problem was someone in the factory put a WX-203 sticker with serial number, build date, etc. The stock picker at SupplyHouse went by that. This time the decision was to ship back the mis-marked tank to confirm. Once it was proved to be incorrect, another tank was shipped. This time it was the correct model and is holding up.
SupplyHouse customer service has been great. Over the weeks of this ordeal I dealt with several customer service reps, all were great. There was Sonya, Bailey, Candice and Angel. All these deserve praise for their efforts.
I will attempt to upload a photo of the WX-202 with incorrect WX-203 sticker. The bottom of box clearly says WX-202, zoom in to read sticker.
Personally I feel bad SupplyHouse had to deal with the poor quality control from Amtrol. I hope they are fairly compensated for the cost and hassle.
Showing 1-10 of 168 reviews
I would buy this product again and again!
Quality tank! Great warranty! Speedy shipping. I didn't realize just how long a time (years!) my old pressure tank was deteriorating and how it was affecting all my water using equipment and even my electricity bill! Holy cow! So glad i found SupplyHouse on line!
Marcia
Michigan
4 months ago
Verified Buyer
Was this review helpful to you?
Great customer service
Bought this tank based on reviews and reputation. What mostly stood out was the customer service from both the manufacturer and Supply House. Excellent and expedient service.
Jeff
Indiana
5 months ago
Verified Buyer
Was this review helpful to you?
First tank lasted 37 years. yes I would buy again
First tank lasted 37 years
JS
Ohio
6 months ago
Verified Buyer
Was this review helpful to you?
Handled quickly
The first tank was damaged in shipping . Called SUPPLYHOUSE.COM ,they quickly sent a return ticket and another shipment was on its way! Very good customer service.
CK
Florida
7 months ago
Verified Buyer
Was this review helpful to you?
I have not had it long enough to give a review on it
Steady water pressure
Joe
Tampa Fl
7 months ago
Verified Buyer
Was this review helpful to you?
Well X Trol Quality Control Issues
This is a challenging review. SupplyHouse gets 5 stars, Amtrol the maker of Well-X-Trol pressure tanks, maybe 1 1/2 stars.
We are on our third tank and seem to have a good one finally. Ordered the first one in July and learned it was defective soon after. Started seeing the telltale rust in toilet bowls. SupplyHouse checked with Amtrol, they agreed to send another tank. I originally ordered a WX-203, what arrived was a WX-202. That is a 20 gallon tank instead of the 32 gallon I ordered. The problem was someone in the factory put a WX-203 sticker with serial number, build date, etc. The stock picker at SupplyHouse went by that. This time the decision was to ship back the mis-marked tank to confirm. Once it was proved to be incorrect, another tank was shipped. This time it was the correct model and is holding up.
SupplyHouse customer service has been great. Over the weeks of this ordeal I dealt with several customer service reps, all were great. There was Sonya, Bailey, Candice and Angel. All these deserve praise for their efforts.
I will attempt to upload a photo of the WX-202 with incorrect WX-203 sticker. The bottom of box clearly says WX-202, zoom in to read sticker.
Personally I feel bad SupplyHouse had to deal with the poor quality control from Amtrol. I hope they are fairly compensated for the cost and hassle.
Steve
Lebanon, Oregon
8 months ago
Verified Buyer
Was this review helpful to you?
this tank worked well for our job
Tank fit in the room and works great!
ab
va
9 months ago
Verified Buyer
Was this review helpful to you?
Best product with the best warranty
This is the best product money can buy represented by a full 7-year warranty, the best in the business
Mort
Richfield, Wisconsin
9 months ago
Verified Buyer
Was this review helpful to you?
So far, so good
Just recently had my plumber install. It certainly is an improvement over the previous tank and bladder. Time will tell.
TJam
Fawnskin, CA
11 months ago
Verified Buyer
Was this review helpful to you?
Warranty replacement for Well-X-Trol tank
SupplyHouse made the whole process very easy.
Stu
Stroudsburg, PA
12 months ago
Verified Buyer
Was this review helpful to you?
Product Q&A
11 Questions11 Questions
Q: What is the draw down at 40-60 setting?
Asked by T 10 years ago
Add your answer
Verified Reply- SupplyHouse StaffThe WX-203 has an 8.6 gallon draw down at 40/60.
Was this review helpful to you?
Q: What should the internal PSI be in the tank?
Asked by Phil 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffThe unit comes pre-charged to 38 PSI. Release or add air as necessary to make the precharge pressure 2 psig below the pressure switch pump cut-in setting.(Example, if you have aWX-202-XL with a precharge of 38psig, and you have a pressure switch setting of 30/50 psig, adjust pre-charge of your WX-202-XL from 38 psig to 28 psig.) For more information please see pg 5 here: http://s3.supplyhouse.com/manuals/1327104462397/70495_PROD_FILE.pdf
Was this review helpful to you?
Q: I have a WX-203 built on Oct 30, 2012. It cycles about tow or three times per minute dropping pressure from about 80 to 40, what is a normal pressure drop cycle? Not sure if I have a problem with the tank holding pressure, the pressure switch or my well pump.
Asked by freddy 11 years ago
Add your answer
Verified Reply- Supplyhouse Staffwe do not have that information, it would be best to contact Amrtrol directly for technical questions
Was this review helpful to you?
- Plumber
the problem is most likely the air pressure setting in the tank. If your switch comes on at 40 psi you should have 37-38 psi of air pressure in the tank/bladder when all of the water pressure is off the system. Start by turning off the power/beaker to the pump open a faucet in the house & let it run until no water is coming out. Take a tire gauge & measure the amount of air that is in the tank it should be 37-38 psi if the switch closes at 40 psi. adjust the air pressure as needed close the faucet & restart the the pump you should notice a lot longer cycle time. When you have the pressure drained if there is still water in the tank the bladder is most likely ruined.
Was this review helpful to you?
Q: I am thinking of getting a WX-203. My existing tank sits on two 8 inch high 6x16" blocks laying side by side to bring it up to water connection. My existing tank is also 15 3/4" diameter. Can I put this tank on the same blocks? What is the dimension of the stand?
Asked by Bip 12 years ago
Add your answer
Verified Reply- Supplyhouse Staffthe exact size is listed on this spec sheet. http://s3.supplyhouse.com/manuals/1327104501242/70497_PROD_FILE.pdf
Was this review helpful to you?
Q: Would this be the right tank to replace a 203LTD? Mine is probably around 20 years old.
Asked by Ken 12 years ago
Add your answer
Verified Reply- SupplyHouse StaffThe WX-203 is a similar unit to the 203LTD and would make a good candidate to replace it.
Was this review helpful to you?
Q: I need to know as this model tank sits ... How high from the ground to water discharge distance is there to the floor.. mine is like 9 inches presently I tee into... ?
Asked by jeff209 13 years ago
Add your answer
Verified Reply- PexSupply StaffThe distance from the floor to the center of the water hookup is 1-15/16".
Was this review helpful to you?
Q: does this model include stand as depicted? thanks paul
Asked by paul 13 years ago
Add your answer
Verified Reply- PexSupply StaffYes, WX-203 tanks do include a stand.
Was this review helpful to you?
Q: Hi, Could a durabase stand be added to this tank as a spacer, to raise the tank tee higher off the floor?
Asked by JT 13 years ago
Add your answer
Verified Reply- PexSupply StaffYes, the DURABASE-15 stand will work with this tank. Part WX-203D includes the WX-203 tank and the durabase stand.
Was this review helpful to you?
Q: What is the connection size?
Asked by Old School 14 years ago
Add your answer
Verified Reply- PexSupply StaffThe connection is 1 inch,
Was this review helpful to you?
Q: Hi: I need this for a cabin where I drain the water system every winter. Is this the tank for me? Does it have a drain valve? Thanks, Tom
Asked by tom 15 years ago
Add your answer
Verified Reply- PexSupply StaffYes, this tank has a drain valve attached to the unit.
Was this review helpful to you?
