Product Highlights
–
2-Way
Sweat Connection
3.5 Cv
3/4"
24V
Normally Closed
Description
–
Erie PopTop Series valve bodies and actuators provide easy installation for a variety of heating and
cooling applications. Valve's actuator can be installed after valve body has been installed onto fan coil, baseboard or air handler.
Features:
Features:
- Direct replacement for all existing two-position PopTop applications
- Hysteresis synchronous motor for long life
- Spring return operation provides a fail-safe
- Valve body rated for 400 psi static pressure
- Available in a variety of voltages
- Actuator mounts directly onto valve body without need for linkages or calibration
- Manual override lever (normally closed only)
- Actuator can be replaced without any tools, or removal of valve from system
Specs
–
| Size: | 3/4" |
|---|---|
| Body Pattern: | 2-Way |
| Connection Type: | Sweat |
| Flow Capacity (Cv): | 3.5 |
| Actuator Type: | General Close-Off On/Off |
| Voltage: | 24V |
| Position: | Normally Closed |
| Wiring: | 18" Leads |
| End Switch: | Yes |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
Compare Similar Products
Brand
Size
Body Pattern
Connection Type
Flow Capacity (Cv)
Voltage
CURRENT ITEM
3/4"
2-Way
Sweat
3.5
24V
4 Replacement Parts
24V Replacement Motor For PopTop Zone Valves
SKU: 30-118-A
Erie3/4" Sweat 2-Way Valve Body (3.5 Cv)
SKU: VT2313
Erie24V AG/AH Replacement PopTop Motor
SKU: 30-158-A
ErieNeed help finding a replacement part?
Fill out the part request form and someone will get back to you shortly.
PART REQUEST FORM
Product Reviews
5 out of 4 reviews
100% would recommend this product
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Showing 1-4 of 4 reviews
Just what I needed and shipped immediately
We have a home with a now 22 year old in floor hydronic heating system and one by one the original Erie zone valves are failing. They can easily be swapped out if one can find "exact" replacements (four wire, 24 V, normally closed) and the Supply House has them for our application. I used to buy just one at a time but now have several in stock as I've learned the hard way that nothing lasts forever. I quickly learned how to test and swap them out in just a few minutes and save myself 300 bucks each time in plumber costs!
Richard
Incline Village, NV
4 years ago
Verified Buyer
Was this review helpful to you?
Excellant product and service.
Simple installation. Only minutes to install.
John
Vermont
5 years ago
Verified Buyer
Was this review helpful to you?
better than than control it replaces
SupplyHouse recommended this valve as a replacement for a 30 yr old Erie control valve that is no longer available. Pop top feature will make future repair much easier. Installed easily and is working perfectly.
GFG
Southern California
6 years ago
Verified Buyer
Was this review helpful to you?
use these exclusively
good quality and easy to wire
boilerman
new hampshire
12 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
1 Question1 Question
Q: Power to zone valve what connects to red wires? what connects to black wires?
Asked by Bob 11 years ago
Add your answer
Verified Reply- Supplyhouse Staffblack wires are your control wires, red wires are your end switch.
Was this review helpful to you?
